3 robots with a load capacity of 210kg and 8 robots with a load capacity of 5kg collaborate to clean and dry at designated points.

Rhythm: 46 seconds (including robot movement time)

Material feeding: Motorized roller conveyor feeding, camera type recognition

Cleaning: Turbulent overall cleaning + compressed air injection into the water jacket for explosion cleaning, 4 small robots with nozzles for fixed-point and fixed-position cleaning.

Drying: Four small robots hold nozzles to positionally blow dry each hole surface, followed by vacuum drying.

Particle size: The particle size of VCT oil holes ≤ 0.3mm (shallow holes)

Drying degree: The surface is relatively dry, and there is no water or cleaning solution in the oil passage holes.

Workpiece material: Aluminum alloy

Workpiece temperature: The temperature difference between the workpiece surface and the room temperature is ≤ ±2℃.

Protection: Double-layer fiberglass reinforced plastic, excellent visibility

*The above product parameters are for reference only. For detailed information, please call for consultation.
